One-Way AN-10 Check Valve

One-Way AN-10 Check Valve

Part Number: 15107 / UPC 00684980000283
Skip to product information

Product Info

P/N 15107 AN-10 One-Way Check Valve
AN-10 inlet to ORB-10 outlet

  • For installation after pump, before regulator.

  • Requires ORB-10 to AN outlet fitting.

  • Gasoline only, not rated for alcohol fuels.

  • This product is not legal for sale or use on emission-controlled vehicles except when used as a direct replacement part matching OEM specifications.

Additional information

High flow one-way check valves designed to prevent back-flow with minimal pressure drop. Ideal to prevent drain back after the fuel pump is turned off, or when dual pumps are used and both pumps may not run simultaneously.

  • CNC-machined billet aluminum and Type II bright dip black anodized finish.

  • AN-10 male inlet, ORB-10 female outlet connections.

  • Ideal configuration for easy installation into filter or fuel pump outlet port, no need for additional lines, hose-ends or fittings.

  • This product is not legal for sale or use on emission-controlled vehicles except when used as a direct replacement part matching OEM specifications.

  • Suitable for use with gasoline fuels only, not alcohol compatible.

  • Use AN-10 o-rings P/N 15623 for installation into ORB-10 port.

  • Compatible ORB-10 to AN outlet adapters include:

    • ORB-10 to AN-12:  P/N 15642

    • ORB-10 to AN-10:  P/N 15608

    • ORB-10 to AN-08:  P/N 15610

    • ORB-10 to AN-06:  P/N 15609



Reviews

One-Way AN-10 Check Valve

One-Way AN-10 Check Valve

Part Number: 15107 / UPC 00684980000283
Regular price $133.95
Sale price $133.95 Regular price

Part Number: 15107 / UPC 00684980000283
View full details

Product Info

P/N 15107 AN-10 One-Way Check Valve
AN-10 inlet to ORB-10 outlet

  • For installation after pump, before regulator.

  • Requires ORB-10 to AN outlet fitting.

  • Gasoline only, not rated for alcohol fuels.

  • This product is not legal for sale or use on emission-controlled vehicles except when used as a direct replacement part matching OEM specifications.

Additional information

High flow one-way check valves designed to prevent back-flow with minimal pressure drop. Ideal to prevent drain back after the fuel pump is turned off, or when dual pumps are used and both pumps may not run simultaneously.

  • CNC-machined billet aluminum and Type II bright dip black anodized finish.

  • AN-10 male inlet, ORB-10 female outlet connections.

  • Ideal configuration for easy installation into filter or fuel pump outlet port, no need for additional lines, hose-ends or fittings.

  • This product is not legal for sale or use on emission-controlled vehicles except when used as a direct replacement part matching OEM specifications.

  • Suitable for use with gasoline fuels only, not alcohol compatible.

  • Use AN-10 o-rings P/N 15623 for installation into ORB-10 port.

  • Compatible ORB-10 to AN outlet adapters include:

    • ORB-10 to AN-12:  P/N 15642

    • ORB-10 to AN-10:  P/N 15608

    • ORB-10 to AN-08:  P/N 15610

    • ORB-10 to AN-06:  P/N 15609



Reviews
