P/N 11202: A2000 Carbureted Fuel Pump
The A2000 flows enough fuel to support the world's quickest nitrous Pro-mods on gasoline, and is the industry's only fuel pump that uses a true diaphragm controlled, adjustable bypass valve, integral to the pump. This design dampens pressure spikes, delivering smoother, more controlled flow and pressure, ensuring more consistent E.T.s and win lights.
The A2000 flows enough fuel to support the world's quickest nitrous Pro-mods on gasoline, and is the industry's only fuel pump that uses a true diaphragm controlled, adjustable bypass valve, integral to the pump. This design dampens pressure spikes, delivering smoother, more controlled flow and pressure, ensuring more consistent E.T.s and win lights.
- High torque, low RPM motor design delivers more than 350 GPH free flow, while developing less current draw than any other pump in its class.
- Adjustable diaphragm bypass valve outperforms ineffective poppet designs, minimizing flow loss and pressure fluctuation to the regulator and carburetor.
- ORB-10 inlet and outlet ports with ORB-8 return and 1/8' NPT gauge port.
- This product is not legal for sale or use on emission-controlled vehicles except when used on a dedicated race vehicle.
- Proprietary seal design eliminates leakage.
- Alcohol compatible.
- Multiple bolt patterns on the bottom of the pump body fit many chassis mounting options.
Specifications
Specifications
| Series | A2000 |
|---|---|
| Maximum Flow Rating | 350 GPH |
| Maximum Pressure | 20 |
| Fuel Type | Gas/E85 |
| Universal Or Specific Fit | Universal |
| Pump Design | Rotary Vane |
| Motor Style | Brushed |
| Integrated Controller | No |
| Pulse Width Modulation Compatible | Yes |
| Fuel Delivery Type | Carbureted |
| Inlet Type | Female Thread |
| Inlet Outside Diameter | ORB-10 |
| Outlet Type | Female Thread |
| Outlet Outside Diameter | ORB-10 |
| Maximum Current Draw | 14 @ 9 psi |
| Voltage | 12 |
| Negative Ground | Yes |
| Wire Quantity | 2 |
| Wiring Harness Included | No |
| Terminal Quantity | 0 |
| Terminal Type | Lead Wire |
| Strainer Included | No |
| Fuel Sending Unit Included | No |
| Regulator Included | No |
| Mounting Bracket Included | Yes |
| Mounting Hardware Included | No |
| Seal And Lock Ring Included | No |
| Gasket Or Seal Included | No |
| Grade Type | Performance |
| Marine Approved | No |
Installation Instructions
Installation Instructions
Product warranty
Product warranty
Retail Purchasers:
- Warranty: 1 year from purchase date with proof.
- Claims: Contact Aeromotive for issues and RGA. Pre-paid shipping required.
- Remedies: Limited to product sale price. Not liable for incidental damages. Not for emission-controlled vehicles.
- Contact: 913-808-2376, option 3 (have part, proof of purchase, pen, paper).
Distributors:
- Warranty Returns: Require RGA and proof of customer purchase. Handled as repair or replacement.
- Stock Adjustments: Annual returns need prior approval and RGA. Over 5% of annual sales incur 15% restocking fee. Account credit only, no cash refunds.
Returns & replacements
Returns & replacements
Returns:
- Accepted within 90 days of purchase.
- Prior authorization required; items must be new and resaleable.
- Call 913-808-2376 to initiate a return and get an RGA.
- Ship unused products in original packaging with proof of purchase.
- You pay return shipping; use a trackable method.
- Refund excludes initial shipping fees and may include up to a 15% restocking fee.
- Refunds processed within 5-10 days of return acceptance.
Defective Items:
- Call 913-808-2376 (Returns and Repairs) for assistance.
- Follow RGA/Warranty protocol for refunds or replacements.
Limits of Responsibility:
- See Product Warranty page for more info.
Price/Description Changes:
- Prices, pictures, and descriptions may change.
- Report discrepancies within 30 days.
- No refunds for price differences on past or future orders.
Promotions:
- Discount codes apply to web store orders only.
- Not valid on previous orders or outside promotion dates.
Reviews
Reviews
Regular price
$599.95
Sale price
$599.95
Regular price
Unit price
per
$50 MAIL-IN REBATE Learn more
