10 Micron Extreme Flow Fuel Filter with AN-16 ORB Ports & Cellulose Element

10 Micron Extreme Flow Fuel Filter with AN-16 ORB Ports & Cellulose Element

Part Number: 12361
Skip to product information

Product Info

P/N 12361: Extreme Flow 10-m Fabric AN-16 ORB Fuel Filter
Max flow filtration for Brushless Gear and Mechanical Fuel Pumps

High-flow cellulose filter ideal for extended service life in gas or diesel fuel applications using mechanical or electric fuel pumps up to 6-GPM.

This product is not legal for sale or use on emission-controlled vehicles except when used as a direct replacement part matching OEM specifications.

When over 6-GPM mechanical or electric pumps are required for ethanol and methanol applications see 10-m Microglass filter Assembly P/N 12364 .

  • High-flow, 10-micron fabric (cellulose) replaceable element.

  • Fabric element for use with gasoline and diesel fuels only.

  • Suitable for up to 6-GPM mechanical or electric fuel pumps.

  • Flows 3,000 lb/hr with a clean pressure drop of less than 3-PSI.

  • AN-16 ORB ports. Fittings available to adapt these filters from AN-16 down to AN-08 line sizes. (see Fittings & Adapters).

  • Extreme-Flow filters feature a tough, Hard-Coat Black finish.

  • 10" long x 2-5/8" diameter.

  • Replacement element P/N 12661




Additional information

An inexpensive insurance policy to protect your investment, proper filtration is key to fuel system performance. Engineered filter solutions are required to achieve protection with minimum restriction. Aeromotive offers a full line of filter options suitable for 200 - 4,000 plus HP applications.  Specialized filter media for gas, ethanol and methanol fuels available.  Our filter assemblies offer unmatched flow, ease of installation and maintenance, along with the impeccable machining and finish you've come to expect from all Aeromotive components.

High-flow cellulose filter ideal for extended service life in gas or diesel fuel applications using mechanical or electric fuel pumps up to 6-GPM.

When over 6-GPM mechanical or electric pumps are required for ethanol and methanol applications see 10-m Microglass filter Assembly P/N 12364 .

  • High-flow, 10-micron fabric (cellulose) replaceable element.

  • Fabric element for use with gasoline and diesel fuels only.

  • Suitable for up to 6-GPM mechanical or electric fuel pumps.

  • Flows 3,000 lb/hr with a clean pressure drop of less than 3-PSI.

  • AN-16 ORB ports. Fittings available to adapt these filters from AN-16 down to AN-08 line sizes. (see Fittings & Adapters).

  • This product is not legal for sale or use on emission-controlled vehicles except when used as a direct replacement part matching OEM specifications.

  • Extreme-Flow filters feature a tough, Hard-Coat Black finish.

  • 10" long x 2-5/8" diameter.

  • Replacement element P/N 12661

Specifications

Fuel Filter Style Inline
Fuel Type Gas / Diesel
Inlet Quantity 1
Inlet Size AN-16
Inlet Attachment Female Thread
Inlet Outside Diameter AN-16
Outlet Quantity 1
Outlet Size AN-16
Outlet Attachment Female Thread
Outlet Outside Diameter AN-16
End 1 Gender Female
End 2 Gender Female
Fitting Type AN-16
Fittings Included No
Filter Element Included Yes
Filter Element Material Cellulose
Micron Rating 100
Smallest Particle Filtered 100 microns
Flow Rate 2000 Pounds Per Hour
Filter Housing Color Black
Filter Housing Finish Anodized
Filter Housing Diameter 2.0 Inches
Filter Housing Length 5.5 Inches
Filter Housing Material Billet Aluminum
Mounting Type External
Mounting Bracket Included No
Clamps Included No
Gasket Or Seal Included Yes
Maximum Fuel Pressure (psi) 70 PSI
Universal Or Specific Fit Universal

filter replacement element

  • Product warranty

    Limited Warranty for Aeromotive Products for the United States of America

    Aeromotive, LLC warrant to the original end user purchaser in the United States that the Aeromotive and Waterman Racing Components branded products (“Product(s)”) shall be free from defects in material and workmanship for the warranty durations set forth in the chart below from the date of purchase or delivery, whichever is later.

     Products Warranty Duration
    • Aeromotive marine pumps
    2 years
    • All other Aeromotive products
    • Waterman Racing Components products
    1 year



    Because Aeromotive, LLC (collectively, the “Company”) cannot control the quality of products sold by unauthorized sellers, this warranty applies only to Products that were purchased from the Company or the Company’s authorized sellers in the United States, unless otherwise prohibited by law. Company reserves the right to reject warranty claims for Products purchased from unauthorized sellers, including unauthorized Internet sites.

    This warranty does not cover any defects due to normal wear and tear, damage due to misuse, alteration to the product, negligence, damage caused by aftermarket applied coatings, discoloration, or corrosion of finished surfaces. This warranty also does not cover damage resulting from collision, improper installation, off-road use, road hazards, the use of exhaust insulating wrap or like products, or rust occurring after installation.

    Purchasers of a Product who wish to make a warranty claim based upon an alleged Product defect should email the Company at techs@aeromotiveinc.com the following information: (1) Product subject to the claim, (2) brief description of the alleged defect, (3) date and place of purchase/delivery, (4) proof of purchase (showing when and where the Product was purchased), and (5) pictures or videos of the Product. If you purchased on an online marketplace, please be sure the proof of purchase shows from whom you purchased (this information is available in your order history). In some instances, Company may instruct you to mail the Product to Company for inspection and/or repair; if such instruction is provided, Company will provide you with a prepaid shipping label. You can also contact the Company Monday – Friday, 8AM – 6:30PM CT at (913) 808-2376.

    Company will replace or repair a defective Product that is covered by this warranty. This
    warranty does not cover the cost of removal or installation. Company will pay for the return shipping of the Product to the purchaser.

    There are no warranties which extend beyond those stated herein. ANY IMPLIED
    WARRANTIES THAT MAY BE APPLICABLE TO PRODUCTS, INCLUDING IMPLIED
    WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE
    LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY. Some States do not
    allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.

    UNDER NO CIRCUMSTANCES SHALL THE COMPANY BE LIABLE FOR ANY SPECIAL,
    INCIDENTAL, OR CONSEQUENTIAL DAMAGES BASED UPON BREACH OF THIS LIMITED
    WARRANTY, BREACH OF CONTRACT OR STRICT LIABILITY. Some States do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.

    This warranty gives you specific legal rights, and you may also have other rights which vary from State to State.

    If you have any questions about whether a seller is authorized, please contact us at (913) 808-2376.

    This warranty supersedes any warranties stated in product manuals or other written materials.

    Effective Date: March 16, 2026

    Returns & replacements

    Returns:

    • Accepted within 90 days of purchase.
    • Prior authorization required; items must be new and resaleable.
    • Call 913-808-2376 to initiate a return and get an RGA.
    • Ship unused products in original packaging with proof of purchase.
    • You pay return shipping; use a trackable method.
    • Refund excludes initial shipping fees and may include up to a 15% restocking fee.
    • Refunds processed within 5-10 days of return acceptance.

    Limits of Responsibility:

    • See Product Warranty page for more info.
