The A2000 flows enough fuel to support the world's quickest nitrous Pro-mods on gasoline, and is the industry's only fuel pump that uses a true diaphragm controlled, adjustable bypass valve, integral to the pump. This design dampens pressure spikes, delivering smoother, more controlled flow and pressure, ensuring more consistent E.T.s and win lights.
- High torque, low RPM motor design delivers more than 350 GPH free flow, while developing less current draw than any other pump in its class.
- Adjustable diaphragm bypass valve outperforms ineffective poppet designs, minimizing flow loss and pressure fluctuation to the regulator and carburetor.
- ORB-10 inlet and outlet ports with ORB-8 return and 1/8' NPT gauge port.
- This product is not legal for sale or use on emission-controlled vehicles except when used on a dedicated race vehicle.
- Proprietary seal design eliminates leakage.
- Alcohol compatible.
- Multiple bolt patterns on the bottom of the pump body fit many chassis mounting options.
Specifications
Specifications
| Series | A2000 |
|---|---|
| Maximum Flow Rating | 350 GPH |
| Maximum Pressure | 20 |
| Fuel Type | Gas/E85 |
| Universal Or Specific Fit | Universal |
| Pump Design | Rotary Vane |
| Motor Style | Brushed |
| Integrated Controller | No |
| Pulse Width Modulation Compatible | Yes |
| Fuel Delivery Type | Carbureted |
| Inlet Type | Female Thread |
| Inlet Outside Diameter | ORB-10 |
| Outlet Type | Female Thread |
| Outlet Outside Diameter | ORB-10 |
| Maximum Current Draw | 14 @ 9 psi |
| Voltage | 12 |
| Negative Ground | Yes |
| Wire Quantity | 2 |
| Wiring Harness Included | No |
| Terminal Quantity | 0 |
| Terminal Type | Lead Wire |
| Strainer Included | No |
| Fuel Sending Unit Included | No |
| Regulator Included | No |
| Mounting Bracket Included | Yes |
| Mounting Hardware Included | No |
| Seal And Lock Ring Included | No |
| Gasket Or Seal Included | No |
| Grade Type | Performance |
| Marine Approved | No |
Installation Instructions
Installation Instructions
Product warranty
Product warranty
Limited Warranty for Pertronix and Aeromotive Products for the United States of America
PerTronix, LLC (for the Pertronix, Taylor, Doug’s, JBA, Patriot, Compu-Fire, and Spyke branded products) and Aeromotive, LLC (for the Aeromotive branded products) respectively warrant to the original end user purchaser in the United States that the Pertronix, Taylor, Doug’s, JBA, Patriot, Compu-Fire, and Spyke branded products (“Product(s)”) shall be free from defects in material and workmanship for the warranty durations set forth in the chart below from the date of purchase or delivery, whichever is later.
| Products | Warranty Duration |
|
2 years |
|
1 year |
Because PerTronix, LLC and Aeromotive, LLC (collectively, the “Company”) cannot control the quality of products sold by unauthorized sellers, this warranty applies only to Products that were purchased from the Company or the Company’s authorized sellers in the United States, unless otherwise prohibited by law. Company reserves the right to reject warranty claims for Products purchased from unauthorized sellers, including unauthorized Internet sites.
This warranty does not cover any defects due to normal wear and tear, damage due to misuse, alteration to the product, negligence, damage caused by aftermarket applied coatings, discoloration, or corrosion of finished surfaces. This warranty also does not cover damage resulting from collision, improper installation, off-road use, road hazards, the use of exhaust insulating wrap or like products, or rust occurring after installation.
Purchasers of a Product who wish to make a warranty claim based upon an alleged Product defect should email the Company at techs@aeromotiveinc.com (for Aeromotive products) or techs@pertronix.com (for PerTronix products) the following information: (1) Product subject to the claim, (2) brief description of the alleged defect, (3) date and place of purchase/delivery, (4) proof of purchase (showing when and where the Product was purchased), and (5) pictures or videos of the Product. If you purchased on an online marketplace, please be sure the proof of purchase shows from whom you purchased (this information is available in your order history). In some instances, Company may instruct you to mail the Product to Company for inspection and/or repair; if such instruction is provided, Company will provide you with a prepaid shipping label. You can also contact the Company Monday – Friday, 8AM – 6:30PM CT at (913) 808-2376.
Company will replace or repair a defective Product that is covered by this warranty. This
warranty does not cover the cost of removal or installation. Company will pay for the return shipping of the Product to the purchaser.
There are no warranties which extend beyond those stated herein. ANY IMPLIED
WARRANTIES THAT MAY BE APPLICABLE TO PRODUCTS, INCLUDING IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY. Some States do not
allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you.
UNDER NO CIRCUMSTANCES SHALL THE COMPANY BE LIABLE FOR ANY SPECIAL,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES BASED UPON BREACH OF THIS LIMITED
WARRANTY, BREACH OF CONTRACT OR STRICT LIABILITY. Some States do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you.
This warranty gives you specific legal rights, and you may also have other rights which vary from State to State.
If you have any questions about whether a seller is authorized, please contact us at (913) 808-2376.
This warranty supersedes any warranties stated in product manuals or other written materials.
Effective Date: March 16, 2026
Returns & replacements
Returns & replacements
Returns:
- Accepted within 90 days of purchase.
- Prior authorization required; items must be new and resaleable.
- Call 913-808-2376 to initiate a return and get an RGA.
- Ship unused products in original packaging with proof of purchase.
- You pay return shipping; use a trackable method.
- Refund excludes initial shipping fees and may include up to a 15% restocking fee.
- Refunds processed within 5-10 days of return acceptance.
Limits of Responsibility:
- See Product Warranty page for more info.
Reviews
Reviews
Couldn't load pickup availability
Emissions Code
Continue Reading to Understand Emissions Codes
View full details
